MPO Female to MPO Female Trunk Cable Assembly 12 Fibers Polarity A
OM5 OFNP Lime Jacket
MPO Female to MPO Female Trunk Cable Assembly 12 Fibers Polarity A
OM5 OFNP Lime Jacket cable contains 12 fibers, with MPO female
connectors at both ends. MPO is a multi fiber connector that can
accommodate multiple fibers in one connector and is commonly used
for high-density fiber cabling. OM5 cable is a type of fiber optic
cable that belongs to multimode fiber and supports transmission
over a wide wavelength range, suitable for high bandwidth
applications, especially in data centers. It is a fiber optic
connection cable mainly used in data centers and high-density fiber
optic networks.
Applications of MPO Trunk Patch Cable
1. Data Center Interconnect
2. High-Density Fiber Management
3. Telecommunication Networks and CATV networks
4. LAN/WAN Premises
Features of MPO MPO Trunk Patch Cable
1. Low insertion loss and high return loss
2. High precision connector
3. PC UPC APC end face polish
4. Up to 288 fibers - ideal for high-density applications
5. 100% factory terminated and tested
6. Pulling eyes are provided as an option to protect the fiber ends
during installation
7. Save installation and reconfiguration time
8. Customized length available
9. ROHS Compliant
Specifications of MPO Trunk Patch Cable
Connector | MPO(Female) |
Fiber Mode | OM5 50/125μm |
Polishing Type | UPC |
Connector IL | 0.35dB Max (0.15dB Typ.) |
Connector RL | ≥20dB |
Breakout Type | 0.3m Equal Breakout |
Glass Fiber | Corning ClearCurve® |
10G Ethernet Distance | 400m at 850nm |
40/100G Ethernet Distance | 150m at 850nm |
Attenuation at 850nm | ≤2.3dB/km |
Attenuation at 1300nm | ≤0.6dB/km |
Installation Tensile Load | 66N |
Tensile Strength (Long/Short Term) | 80/240N |
Storage Temperature | -40 to +85°C |
Operating Temperature | -20 to +85°C |
