SC UPC To SC UPC Single Mode Duplex Plastic Fiber Optic Adapter –
Blue
A fiber optic adapter, often referred to as a coupler, is a compact
device designed to connect or terminate fiber optic cables and
connectors between two fiber optic lines. By accurately linking two
connectors, fiber optic adapters maximize light transmission while
minimizing loss. Additionally, these adapters offer several
advantages, including low insertion loss, excellent
interchangeability, and high reproducibility. FiberMania provides a
diverse selection of mating sleeves and hybrid adapters, including
specialized male-to-female hybrid fiber optic adapters.
Features
1. Allow for easy snap-in installation without tools
2. Prevent the adapter from dust and keep it clean
3. Low insertion loss with high-precision alignment
4. Made of high quality Zirconia ceramic sleeves
5. 100% tested on optical performance (Insertion Loss & Return
Loss)
6. End-face geometry requirement complies to Telcordia GR-326-CORE
For end-to-end fiber cable connectivity
7. Available in singlemode and multimode, including APC and various
colours
8. Female to female & male to female adapters available
9. Hybrid, Shuttered and Metal adapters available
10. Coloured for easy indentification
Application
1. FTTX
2. LAN and WAN
3. Data center
4. Telecommunication networks
5. Premise installations
6. LAN and WAN
7. FTTX
8. Broadband network
Mechanical Specifications
| Operating Temperature | -40 to +75º C |
| Storage Temperature | -40 to +85º C |
| Temperature Cycling | -40 to +75º C, 40 cycles=0.2dB change |
| High Temperature | 70˚c for 96Hrs, <0.4dB change |
| Damp Heat | 40º C at 93%RH for 96 Hrs, <0.4dB change |
| Vibration-Mated Pair | 10-55Hz, 1.5mm P to P <0.2dB change |
| Mating Durability | 500 Mating Cycles, clean every 25, <0.2dB change |
FAQ
Q1: What is the warranty of FiberMania's fiber patch cord?
A: FiberMania warrants that all fiber patch cords supplied are free
from defects in material and workmanship for a period of five (5)
years from the date of supply. All fiber optic bulk cables are UL
profiled and every single cable is 100% tested.
Q2: Is it possible to customize our brand information on your fiber
cable?
A: Yes, we can print your brand name onto our cable jacket and 1KM
total cable length is requested.
Q3: Can you do 3D interferometer test?
A: Yes, we do the 3D test per our customer's request, we can have
the pass rate over 90% and even 100% if necessary.
Q4: What is your MOQ of your products?
A: We only have MOQ for some special customized cable order, we
request 1km as the total length of the bulk cable, you may consider
stock the bulk cable with us for your urgent order production.
Q5: Are free samples available from you?
A: Yes, we are always happy to offer the free samples for all of
our customers' projects provided that the total cost is under 50 US
dollars.
Q6: Do you accept OEM and ODM orders?
A: Absolutely yes, we have been doing OEM services since we start
in this business, and for every single label, printing, bag and
carton design, we always treat it seriously and do it nicely. Our
engineers can help you with your current design and even can open
the new tooling for your specific project.
