LC/UPC 6 Cores Bundle Fan-out Fiber Optic Pigtail Multimode
62.5/125um Orange Jacket
A fiber pigtail is a great solution for fusion splicing inside of a
fiber patch panel or fiber optic patch panel. Each strand is
terminated on one end and the other end is left blunt so that it
can be spliced to your drop cable to eliminate the need for
annoying field terminations and save time. FiberMania manufactures
a full line of fiber optic pigtails, including simplex, duplex, 4
fibers, 6 fibers, 8 fibers, 12 fibers, 24 fibers, 48 fibers, and so
on. The multi-strand pigtails we supplied are packed with a good
blister to guarantee the fiber is not easily broken. Each fiber
strand in the kit has a color-coded buffer for easy identification
and the colors are industry standard.
Applications
1. CATV, LAN, WAN
2. Test and measurement
3. Telecommunication networks
4. Premise installations
5. Video and military active device termination
Features
1. Low insertion loss and back reflection loss
2. Good exchangeability and good durability
3. Meets ISO9001, ROHS, and Bell core GR 326-core standards
4. Available in 4 fibers, 6 fibers, 8 fibers, 12 fibers, 24 fibers
Specifications
| Characteristics | Standard Fiber Cable Assemblies |
Fiber Count | 6 |
Fiber Grade | Bend Insensitive |
| Ferrule Materials | Zirconia Ceramic |
| Fiber Type | OM1 62.5/125 μm |
| Testing Wavelength | 850/1300 nm |
Durability | 1000 Times |
Min. Bend Radius(Fiber Cable) | 20/10D (Dynamic/Static) |
Interchangeability | ≤0.2 dB |
Vibration | ≤0.2 dB |
| Operating Temp. (C) | -20℃ ~+70℃ |
| Storage Temp. (°C) | -40℃ ~ +85℃ |
FAQ
Q1: What is the warranty of FiberMania's fiber patch cord?
A: FiberMania warrants that all fiber patch cords supplied are free
from defects in material and workmanship for a period of five (5)
years from the date of supply. All fiber optic bulk cables are UL
profiled and every single cable is 100% tested.
Q2: Is it possible to customize our brand information on your fiber
cable?
A: Yes, we can print your brand name onto our cable jacket and 1KM
total cable length is requested.
Q3: Can you do 3D interferometer test?
A: Yes, we do the 3D test per our customer's request, we can have
the pass rate over 90% and even 100% if necessary.
Q4: What is your MOQ of your products?
A: We only have MOQ for some special customized cable order, we
request 1km as the total length of the bulk cable, you may consider
stock the bulk cable with us for your urgent order production.
Q5: Are free samples available from you?
A: Yes, we are always happy to offer the free samples for all of
our customers' projects provided that the total cost is under 50 US
dollars.
Q6: Do you accept OEM and ODM orders?
A: Absolutely yes, we have been doing OEM services since we start
in this business, and for every single label, printing, bag and
carton design, we always treat it seriously and do it nicely. Our
engineers can help you with your current design and even can open
the new tooling for your specific project.
