GYTA Fiber Optic Cable Loose Tube 24 Core Single Mode For Communication

Ask Lasest Price
Brand Name :	FIBERMANIA
Model Number :	GYTA-C-F-E (C=Cores, F=Fiber Mode, E=PE Jacket)
Certification :	ISO, UL, CE, RoHS
Price :	Negotiable
Payment Terms :	T/T, Western Union, L/C
Supply Ability :	1000 Pieces

Add to Cart

Product Details
Company Profile

GYTA Fiber Optic Cable Loose Tube 24 Core Single Mode For Communication

GYTA Aluminum tape Layer Loose Tube Outdoor Optical Fiber Cable

GYTA Aluminum Tape Layer Loose Tube Outdoor Optical Fiber Cable is an outdoor communication optical cable that adopts a loose tube structure and has a metal reinforcement at the center of the cable core. The plastic coated aluminum tape longitudinal wrapping provides additional mechanical protection and enhances the cable's ability to withstand compression and flattening. The outermost layer is a polyethylene (PE) sheath, which provides excellent resistance to ultraviolet radiation and environmental stress cracking. The design of this optical cable makes it very suitable for outdoor environments, including pipelines, aerial/lashed and buried installations.

we manufactures a wide range of cables from 2-144fibers with a variety of designs to meet the demands of most installation conditions. Only the highest quality materials are used in our fiber optic cables to ensure that the cable strength and optical integrity are not compromised. Rugged jacket materials and the addition of armor provide the right level of protection.

Features

1. Good mechanical and temperature characteristics;

2. Good lateral compression and flexibility;

3. Small cable diameter, light weight, easy to connect and support large capacity of data transmission;

4. Flame retardant characteristics meet the requirements of relevant standards;

Application

1. Adopted to outdoor distribution;
2. Suitable for aerial, pipeline laying method;
3. Long distance and local area network communication.

Specification

Cable Parameter
Item		Specification
Fiber Count		2	4
Sub-unit Jacket	Material	LSZH
	Thickness	0.4mm±0.05mm
	OD	2.0mm±0.2mm
Armored Layer	Material	SUS204
	OD	4.8mm±0.3mm	6.0mm±0.3mm
	Thickness	0.4mm±0.05mm
	Gap	0.3mm±0.10mm
Strength Member		Aramid Yarn
Outer Jacket	Material	LSZH
	Color	Black
	Thickness	0.9mm±0.1mm	1.1mm±0.1mm
	OD	7.0mm±0.3mm	7.5mm±0.1mm 8.0mm±0.1mm

Mechanical and Environmental Characteristics
Item		Specification
Fiber Count		2	4
Tension Resistance (N)	Long Term	≥ 600	≥ 800
	Short Term	≥ 1000	≥ 1200
Crush Resistance (N/10cm)		≥ 3000
Nominal Weight (kg/km)		65	85
Operating Temperature ( ºC)		-40 ~ +80
Storage Temperature ( ºC)		-40 ~ +80

Fiber Parameters
Single Mode
Item		Unit	G652D	G657A1	G657A2
Mode Field Diameter	1310nm	μm	9.1±0.4	8.8±0.4	8.8±0.4
Mode Field Diameter	1550nm	μm	10.4±0.5	9.8±0.5	9.8±0.5
Cladding Diameter		μm	125±1	125±0.7	125±0.7
Cladding Non-circularity		%	≤ 1	≤ 0.7	≤ 0.7
Core-cladding Concentricity Error		μm	≤ 0.6	≤ 0.5	≤ 0.5
Coating Diameter		μm	245±7	245±5	245±5
Coating Non-circularity		%	≤ 6.0	≤ 6.0	≤ 6.0
Cladding-coating Concentricity Error		μm	≤ 12.0	≤ 12.0	≤ 12.0
Cable Cutoff Wavelength		nm	≤ 1260	≤ 1260	≤ 1260
Attenuation Coefficient	1310nm	dB/km	≤ 0.4	≤ 0.4	≤ 0.4
Attenuation Coefficient	1550nm	dB/km	≤ 0.3	≤ 0.3	≤ 0.3

Multimode
Item		Unit	62.5/125	50/125	OM3-150	OM3-300	OM4
Core Diameter		μm	62.5±2.5	50±2.5	50±2.5	50±2.5	50±2.5
Cladding Diameter		μm	125±1.0	125±1.0	125±1.0	125±1.0	125±1.0
Core Non-circularity		%	≤ 5.0	≤ 5.0	≤ 5.0	≤ 5.0	≤ 5.0
Cladding Non-circularity		%	≤ 1.0	≤ 1.0	≤ 1.0	≤ 1.0	≤ 1.0
Core-cladding Concentricity Error		μm	≤ 1.5	≤ 1.5	≤ 1.0	≤ 1.0	≤ 1.0
Coating Diameter		μm	245±7	245±7	245±7	245±7	245±7
Coating Non-circularity		%	≤ 6.0	≤ 6.0	≤ 6.0	≤ 6.0	≤ 6.0
Cladding-coating Concentricity		μm	≤ 12.0	≤ 12.0	≤ 12.0	≤ 12.0	≤ 12.0
OFL Bandwidth	850nm	MHz·km	≥ 160	≥ 500	≥ 700	≥ 1500	≥ 3500
OFL Bandwidth	1310nm	MHz·km	≥ 500	≥ 500	≥ 500	≥ 500	≥ 500
Attenuation Coefficient	850nm	dB/km	≤ 3.0	≤ 3.0	≤ 3.0	≤ 3.0	≤ 3.0
Attenuation Coefficient	1310nm	dB/km	≤ 1.0	≤ 1.0	≤ 1.0	≤ 1.0	≤ 1.0

FAQ

Q1: What is the warranty of FiberMania's fiber patch cord?
A: FiberMania warrants that all fiber patch cords supplied are free from defects in material and workmanship for a period of
five (5) years from the date of supply. All fiber optic bulk cables are UL profiled and every single cable is 100% tested.

Q2: Is it possible to customize our brand information on your fiber cable?
A: Yes, we can print your brand name onto our cable jacket and 1KM total cable length is requested.

Q3: Can you do 3D interferometer test?
A: Yes, we do the 3D test per our customer's request, we can have the pass rate over 90% and even 100% if necessary.

Q4: What is your MOQ of your products?
A: We only have MOQ for some special customized cable order, we request 1km as the total length of the bulk cable, you may
consider stock the bulk cable with us for your urgent order production.

Q5: Are free samples available from you?
A: Yes, we are always happy to offer the free samples for all of our customers' projects provided that the total cost is under
50 US dollars.

Q6: Do you accept OEM and ODM orders?
A: Absolutely yes, we have been doing OEM services since we start in this business, and for every single label, printing, bag and
carton design, we always treat it seriously and do it nicely. Our engineers can help you with your current design and even can open
the new tooling for your specific project.
