1U 19inch LC Adapter Panel 12 Ports Loaded With LC Duplex Single
Mode or Multimode Adapter
This 12-port rack mount adapter plate is designed to fit a standard
19" 1U panel and is equipped with 12 LC beige duplex adapters. This
faceplate complies with all applicable standards and can be
customized with any array of adapters. Adapters are included.
FiberMania offers a diverse selection of 1U, 12, and 24 fiber optic
network adapter plates. Each adapter plate is 1U in height (Rack
Unit) and tailored for mounting in a 19" network rack. They are
available in various configurations, including LC, LC/APC, SC,
SC/APC, MTP, and MPO adapters. FiberMania adapter plates can be
supplied either unloaded or preloaded with adapters to suit your
needs.
Features
1. Fits 1U (Rack Unit) of space
2. Designed to mount to a 19" network rack
3. All metal construction
4. Black powder Coat
5. Interchangeable for a wide range of products
6. Easy to use and Install
7. RoHS compliant
8. Available with LC, LC/APC, SC, SC/APC, MTP and MPO adapter
configurations
9. Available in multiple colors
Application
1. Data center
2. Telecommunication networks
3. Premise installations
4. LAN and WAN
5. FTTX
6. Broadband network
Mechanical Specifications
| Operating Temperature | -40 to +75º C |
| Storage Temperature | -40 to +85º C |
| Temperature Cycling | -40 to +75º C, 40 cycles=0.2dB change |
| High Temperature | 70˚c for 96Hrs, <0.4dB change |
| Damp Heat | 40º C at 93%RH for 96 Hrs, <0.4dB change |
| Vibration-Mated Pair | 10-55Hz, 1.5mm P to P <0.2dB change |
| Mating Durability | 500 Mating Cycles, clean every 25, <0.2dB change |
FAQ
Q1: What is the warranty of FiberMania's fiber patch cord?
A: FiberMania warrants that all fiber patch cords supplied are free
from defects in material and workmanship for a period of five (5)
years from the date of supply. All fiber optic bulk cables are UL
profiled and every single cable is 100% tested.
Q2: Is it possible to customize our brand information on your fiber
cable?
A: Yes, we can print your brand name onto our cable jacket and 1KM
total cable length is requested.
Q3: Can you do 3D interferometer test?
A: Yes, we do the 3D test per our customer's request, we can have
the pass rate over 90% and even 100% if necessary.
Q4: What is your MOQ of your products?
A: We only have MOQ for some special customized cable order, we
request 1km as the total length of the bulk cable, you may consider
stock the bulk cable with us for your urgent order production.
Q5: Are free samples available from you?
A: Yes, we are always happy to offer the free samples for all of
our customers' projects provided that the total cost is under 50 US
dollars.
Q6: Do you accept OEM and ODM orders?
A: Absolutely yes, we have been doing OEM services since we start
in this business, and for every single label, printing, bag and
carton design, we always treat it seriously and do it nicely. Our
engineers can help you with your current design and even can open
the new tooling for your specific project.
